Description

Additional Information:

1.8m H x 2.1m L Cattle Panel Light
– Size: 1800mm(H) x 2100mm (W)
– Vertical pipe: 50mm x 50mm stiles, 1.6mm Thick
– Horizontal rail: 30mm x 60mm rail, 1.6mm thick x 6 Oval

2.3m H X 2.2m L Cattle Gate Medium
– Size: 2300mm(H) x 2200mm (W)
– Vertical pipe: 50mm x 50mm stiles, 1.6mm Thick
– Horizontal rail: 40mm x 80mm rail, 1.6mm thick x 6 Oval

Cattle Crush Heavy Duty
– Dimensions: 3050mm L x 850mm W x 2250mm H
– Include 1× Headbail with Manual Wrench, 1 x Heavy Duty Sliding Gate, 2 x Cattle Gate Panel on each Side
– Full 360 degree welded
– All tubes are 50x50x2mm
– With lugs, pins and caps
– Total 8 doors with spring latched lock

Cattle Adjustable Loading Ramp With Winch

– Height: 3200mm, Length: 2820mm, Width: 1420mm
– Adjustable Ramp Height: 860mm~1460mm
– Ramp Size: 720mm Width, 3230mm Length
– Vertical Frame: 50x50x2mm
– Top Side Long Tube: 40x40x2mm
– Side Galvanized Sheet: 1.6mm
– Galvanized Footboard 2mm thick

Note: Cattle yard designs can be modified as per your requirement.
